異徑三通
|
Nominal |
Socket Type |
Structural Diameter |
|
SIZE |
d1 |
d2 |
I |
D |
d |
L |
|
3/4"*1/2" |
26.87 |
26.57 |
27.00 |
35.00 |
22.00 |
84.00 |
|
1"*3/4" |
33.65 |
33.27 |
30.00 |
44.00 |
30.00 |
96.00 |
|
1-1/4"*1" |
42.42 |
42.04 |
34.00 |
54.00 |
38.00 |
114.00 |
|
1-1/2"*1-1/4" |
48.56 |
48.11 |
37.00 |
60.00 |
44.00 |
126.00 |
|
2"*1-1/2" |
60.63 |
60.17 |
41.00 |
73.00 |
54.00 |
146.00 |
|
2-1/1"*2" |
73.38 |
72.85 |
46.50 |
88.00 |
67.00 |
171.00 |
|
3"*1-1/2" |
89.31 |
88.70 |
50.00 |
105.00 |
82.00 |
194.00 |
|
3"*2" |
89.31 |
88.70 |
50.00 |
105.00 |
82.00 |
194.00 |
|
4"*2" |
114.76 |
141.10 |
60.00 |
132.00 |
106.00 |
238.00 |
|
4"*3" |
114.76 |
141.10 |
60.00 |
132.00 |
106.00 |
238.00 |
